Free 2x4 Workbench Plans with Cut List (Beginner Friendly)

A workbench is the best first big project you can build. This free 2x4 workbench plan makes a sturdy 60 × 24 inch bench (152 × 61 cm), 36 inches tall, with a full lower shelf for tools and lumber. You need just six 2x4 studs, one sheet of 3/4-inch plywood, screws and one free Saturday. Every cut is a straight crosscut, so it's ideal if you've never built furniture before.

Below you'll find the materials list, the cut list, the tools, and step-by-step instructions. If you're brand new, read our woodworking for beginners roadmap first, and see how to read woodworking plans if any of the terms below are unfamiliar.

Workbench at a glance

Materials list

• 6 × 2x4 studs, 8 ft long (buy a 7th as a spare if you can)
• 1 × sheet of 3/4 in plywood, 4 × 8 ft (sanded one side is nicest for the top)
• About 50 × 3 in construction or wood screws (for the frame)
• About 40 × 1-1/4 in wood screws (for the plywood)
• Wood glue (optional, makes the frame even stiffer)
• Sandpaper (120 and 180 grit) and a finish (optional)

Tip: Ask the store to rip the plywood sheet at 24 inches. The 24-inch strip becomes your top, and the remaining strip (about 23-7/8 inches) gives you the shelf. It also makes the sheet much easier to carry home.

Cut list

Remember that a 2x4 actually measures 1-1/2 × 3-1/2 inches. All sizes below are actual sizes.

How to cut the 2x4s with almost no waste

• Boards 1–4: one long rail (57 in) + one leg (35-1/4 in) each
• Boards 5–6: three short rails (18 in) each. Keep the offcuts for spacer blocks.

This layout also works with "precut" 92-5/8 inch wall studs, but there's very little to spare, so true 8 ft (96 in) boards are easier.

Tools you'll need

• Tape measure, speed square and pencil
• Circular saw or miter saw
• Jigsaw (for the shelf notches)
• Drill/driver with a countersink bit
• 2–4 clamps
• Safety glasses and hearing protection

New to these tools? Our list of essential woodworking tools for beginners explains each one.

Step-by-step instructions

Step 1: Cut all the parts

Cut every part on the cut list and label it with a pencil (A, B, C...). Check that the four legs are exactly the same length. If they differ, the bench will rock.

Step 2: Build the top frame

Lay two long rails (B) on their edges, parallel, on a flat floor. Place one short rail (C) between them at each end and one in the middle (its center at 28-1/2 in from either end). The frame should measure 57 × 21 inches outside. Drill pilot holes and drive two 3 in screws through the long rail into the end of each short rail. Add glue if you like.

Check for square: measure both diagonals. When they match, the frame is square.

Step 3: Build the bottom frame

Repeat step 2 with the remaining two long rails and three short rails. You now have two identical frames.

Step 4: Attach the legs to the top frame

Flip the top frame upside down on the floor. Stand a leg (A) in one inside corner with its end on the floor, so the top of the leg is flush with the top of the frame, and its wide face is against the long rail. Clamp it, then drive two 3 in screws through the long rail into the leg and two through the short rail into the leg's edge. Repeat for all four corners.

Step 5: Attach the bottom frame

Cut four 6 in spacer blocks from your offcuts and set them on the floor. Rest the bottom frame on the blocks. Turn the top assembly right side up, lift it, and lower it over the bottom frame so the legs sit inside the bottom frame's corners, just like at the top. Screw the bottom frame to each leg the same way. Remove the blocks. The shelf frame now sits 6 inches off the floor.

Step 6: Check that it's level

Set the base on a flat floor and press on each corner. If it rocks, find the long leg and sand or trim a tiny amount off its bottom.

Step 7: Fit the shelf

Mark a 5 × 3 inch notch at each corner of the shelf (E) and cut them out with a jigsaw. Drop the shelf onto the bottom frame, around the legs, and fasten it with 1-1/4 in screws every 8 to 10 inches.

Step 8: Attach the top

Center the top (D) on the frame so it overhangs 1-1/2 inches on every side. The overhang gives you room to clamp work to the bench. Countersink 1-1/4 in screws every 8 to 10 inches into the frame below, so no screw heads stick up.

Step 9: Sand and finish

Ease all sharp edges and corners with 120 grit sandpaper. A couple of coats of wipe-on polyurethane or paste wax on the top helps glue drips pop off. Leave the legs bare if you like.

Customize your workbench

• Change the height: leg length = desired height minus 3/4 in. Many people like a bench a little below hip height. 34 to 38 inches suits most adults.
• Make it longer: add the same amount to the long rails and the top. Add another middle short rail for every extra 2 feet.
• Add casters: heavy-duty locking casters let you roll it out of the way. Shorten the legs by the caster height.
• Add a vise: a front vise turns it into a real woodworking bench.
• Add a pegboard back or a power strip for tools you use every day.

Next projects for your workshop

Now that you have a bench, put the rest of your garage in order with our DIY wood garage storage shelves. They use the same simple frame-and-screw method.

Save this for later

Pin this guide to your woodworking board on Pinterest so it is ready when you head to the shop.

Save to Pinterest

FAQ

How many 2x4s do I need for a workbench?

This 60 × 24 inch bench uses six 8 ft 2x4s, plus one sheet of plywood for the top and shelf.

What is the best height for a workbench?

Most adults are comfortable between 34 and 38 inches. This plan is 36 inches; change the leg length to adjust it.

Can I use 2x4s for the top instead of plywood?

Yes. You can lay 2x4s on edge, glue and screw them together, and flatten the top. It's heavier and more work, which is why plywood is easier for a first bench.

Do I need glue as well as screws?

Screws alone work fine. Glue makes the frame stiffer, but the bench can't be taken apart later.
